Super Junction SJ7N60 N-Channel MOSFET 7A 600V with 600V Drain-Source Breakdown Voltage

Model NO. : SJ7N60

Structure : Super Junction

Material : Silicon

Transport Package : Tube

Specification : High Power

Trademark : JF

Origin : China

HS Code : 85411000

Supply Ability : 10000000000piece/Year

Place of Origin : China

Certification : ISO9001:2015, ISO14001:2015, IATF16949

MOQ : 3,000 Pieces

Price : Negotiable

Delivery Time : Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays

Payment Terms : LC, T/T, PayPal

Contact Now

Super Junction N-Channel Power MOSFET
Electronics Component

Part Number: SJ7N60

Major Parameter:

Type	Channel	VDSS(V) (MAX)	ID(A) (MAX)	PD(W) (MAX)	VGS(V) (MAX)	VTH(V)	Rds(on)(Ω) @10V (Typ)	Rds(on)(Ω) @10V (max)	Rds(on)(Ω) @4.5V(Typ)	ESD protection for G-S(Y/N)	Outline code
SJ25N50	N	500	22		±30	2.5~4.5	0.12
SJ4N60	N	600	4		±30	2~4	0.90				TO-220AB: ITO-220AB:F TO-263:D TO-252:M TO-262:E TO-251:N TO-247:P
SJ7N60	N	600	7		±30	2~4	0.58
SJ11N60	N	600	11		±30	2~4	0.38
SJ13N60	N	600	13		±30	2~4	0.34
SJ18N60	N	600	18		±30	2~4	0.22
SJ20N60	N	600	20		±30	2.5~4.0	0.17
SJ21N60	N	600	21		±30	2.5~4.0	0.13
SJ47N60	N	600	47		±30	2~4	0.06
SJ77N60	N	600	77		±30	2.5~4.5	0.035
SJ4N65	N	650	4		±30	2~4	1.00
SJ5N65	N	650	5		±30	2.5~4.5	0.85
SJ7N65	N	650	7		±30	2~4	0.62
SJ11N65	N	650	11		±30	2~4	0.40
SJ13N65	N	650	13		±30	2~4	0.36
SJ18N65	N	650	18		±30	2~4	0.25
SJ20N65	N	650	20		±30	2~4	0.19
SJ22N65	N	650	22		±30	2~4	0.15
SJ47N65	N	650	47		±30	2~4	0.07
SJ7N70	N	700	7		±30	2.5~4.5	0.65
SJ11N70	N	700	11		±30	2~4	0.43
SJ20N80	N	800	20		±30	2.5~4.5	0.22

Brand: JF

Package: ITO-220AB/ TO-220AB/ TO-263/ TO-252/ TO-262/ TO-251/ TO-247/ TO-3P
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

· Fast switching capability

· Lead free in compliance with EU RoHS directive.

· Improved dv dt capability high ruggedness

Application:
Used in power supply, lighting, auto, home appliance field
Super Junction SJ7N60 N-Channel MOSFET 7A 600V with 600V Drain-Source Breakdown Voltage

Super Junction SJ7N60 N-Channel MOSFET 7A 600V with 600V Drain-Source Breakdown Voltage

Super Junction SJ7N60 N-Channel MOSFET 7A 600V with 600V Drain-Source Breakdown Voltage Images
